Key Features
Controlled Excavation with Minimal Micro‑Cracking & Overbreak
- Little or no micro cracking of the ground outside the excavation line. (Cracking from hammers has been shown to reach up to 2m, depending on rock type). This can cause issues with existing infrastructure.
- Minimised overbreak of trench line.
Low‑Impact Trenching for Safer, More Stable Excavations
- Minimal disturbance of trench face making for a safer more intact trench.
- Lower noise impact than other methods.
- Lower vibration impact.
Onsite Material Reuse with Proven, Versatile Antraquip TechnologyTechnology
- Ability to reuse the material onsite as hardfill, thus reducing waste and increasing site efficiency.
- Extremely reliable tools and Antraquip also have a range of Soft Soil mixing attachments which have used in NZ for Mud-Crete.
Specifications
| UNIT | AQC180 | ACQ320 | |
| Cutting Depth | in (mm) | 16- 30(400-750) | 24-48 (600-1.200) |
| Cutting Wheel Diameter | in (mm) | 3- 8(80- 200) | 4 – 16(100-405) |
| Rated Power | HP (kW) | 48- 80(1,200-2.000) | 60-118(1,500-3.000) |
| Carrier Weight | tons | 15-35 | 35 – 65 |
| Recommended Oil Flow | GPM (L/min) | 52 – 80(200 – 300) | 80-160(300-600) |
| Torque Output at 375 bar | ft Ibs (Nm) | 16,600(22,500) | 38,350(52.000) |
| Cutting Force at 375 bar | Ibs (N) | 3,640-8,115 (16.200-36,100) | 9,575-16,700 (42,600-74,300) |
