Key Features
Dozer Blade
Integrating a heavy-duty dozer blade significantly elevates this drilling rig’s versatility, providing the site-clearing agility of an excavator without compromising core foundation power. This hydraulic feature acts as a primary stabilizer, instantly leveling uneven terrain to prevent machine inclination and ensure a perfectly plumb mast.
Rubber Tracks
The rubber track system on our new foundation drilling rig is specifically engineered to maximize mobility and surface preservation in sensitive urban environments.
It significantly reduces noise levels and dampens chassis vibrations, facilitating quieter operations in high-density residential zones.
Automatic functions
Automatic functions allow the operator to reduce rig-up time and get productivity.
With a push of a button, the operator can make use of automatic functions including Verticality of the mast, Automatic Rig-up, Automatic return to drilling point and rotary auto drive.
Specifications
| HPM 25B Specifications | |
|---|---|
| Base | CAT®315 |
| Drilling Depth | 16.8 m |
| Drilling Diameter | |
| Operating Weight | 20,000 kg |
| Rotary Torque | |
| Max. Effective Torque | 35 kNm |
| Working Speed | 16–90 rpm |
| Discharge Speed | 60-100 rpm |
| Main Winch Pull | 72 kN |
| Transport Weight | 20,000 kg |
| Transport Width | 2490mm |
| Transport Height | 3000 mm |
| Crowd Type | Cylinder Crowd Pull |
| Max. Crowd Force | 110 kN |
| Crowd Stroke | 1120 mm |
