BOSS ATTACHMENTS Telescopic Excavator Arm

/

Product Overview

Step into a new era of excavation efficiency – introducing the BOSS EXTRACTOR Series, the pinnacle of safety and technological advancement. Designed to redefine productivity in the industry, this telescopic clamshell boasts unparalleled extraction rates and safety standards. Experience the future of excavation technology – experience the BOSS EXTRACTOR Series.

Key Features

Unparalleled Efficiency

With the capability to reach depths of up to 50 meters, this groundbreaking equipment elevates deep excavation to new heights. But its innovation doesn’t end there – with ultra-fast cycle times, it slashes deep excavation bulk load out costs by a remarkable 75% while simultaneously increasing cycle times.

Unbeatable Safety & Efficiency

Safety and efficiency go hand in hand with BOSS EXTRACTOR. Our twin-axis camera system provides a comprehensive view, while the optional lockout system maintains safe operation limits. Excavate like a pro while keeping safety at the forefront.

Increased Production – Lower Operating Costs

From compact excavators to heavy-duty giants, our BOSS EXTRACTOR series boasts models suitable for machines ranging from 14 tons to 110 tons, providing unmatched efficiency across the spectrum.

Specifications

MODEL	BE2120	BE2324	BE2527	BE2732	BE2534	BE2734	BE3034	BE3045	BE3545	BE4045
MACHINE WEIGHT (ton)	20~24 Ton	24~27	27~32	32~38	34~45	34~45	34~45	45~50	45~50	45~50
DIGGING DEPTH (M)	21	24	32	32	34	34	34	45	35	40
DIGGING DEPTH (FT)	68.9	75.5	82	88.6	82	88.6	98.4	98.4	114.8	131.2
CLAMSHELL BUCKET HYD. ROTATION(TWO-CYLINDER) TOOTH TYPE	SCB20- 900H	SCB20- 1300H	SCB30- 1100H	SCB30- 1100H	SCB40- 1500H	SCB40- 1400H	SCB40- 1300H	SCB50- 1200H	HCB40- 13M	HCB40- 13M
CLAMSHELL ROTATION TYPE	H/M	H/M	H/M	H/M	H/M	H/M	H/M	H/M	H/M	M
CAPACITY (cu.m)	0.6	0.8	1	1	1.6	1.5	1.4	1.7	1.3	1.4
CAPACITY (cu.ft)	21.2	28.3	35.3	35.3	56.5	52.9	49.4	60	45.9	49.4
WEIGHT (kg)	1125	1350	1560	1560	2160	2040	1920	2280	1830	1920
DOWN SPEED	11.1	12.9	15.1	18	15.1	19.1	19.1	15	22	22.7
UP SPEED	9.1	10.6	10.3	15	10.3	15.9	15.9	12.5	17	22.7
PRODUCTIVITYV(m^3/hr)	52.4	64.7	75.9	91.6	75.9	88.4	88.4	123.6	76.7	74.8
PRODUCTIVITYV(ft^3/hr)	1850.5	2284.9	2680.4	3234.8	2680.4	3121.8	3121.8	4364.9	2708.6	–

*H – Hydraulic **M- Manual

Industry

Construction

Forestry

Mining

Recycling

Type

Telescopic Excavator Arm

Machine

Excavator

Interested in the Product?

Get the right attachment for the job — faster, tougher, and built for NZ conditions.
Let’s enquire about how Boss can deliver results for you.
